Technical Specifications

Powertrain & Battery
Motor BLDC Motor, 48V (1.0kW OR 1.2kW)
Battery Lead Acid (12V x 4 Nos.) 120Ah OR 130 Ah
Battery Charger 48V, 15Amp, SMPS Type
Controller 48 V, 50 Amps, 24 Tube MOSFET
Differential 35 inch direct drive (Single speed OR Twin speed)
Electricals
DC-DC Converter 48V-12V, 15Amp
System Voltage DC, 12V
Speedometer Digital OR Analog
Horn 12V, I Cat Approved
Head light DC 12V, HS1 Bulb, High BeamLow Beam
Lights (Front Indicator / Position lamp, Licence lamp, Indicator / Reverse lamp, Parking/Brake lamp) DC 12V, LED Type
Dimensions
Overall Length (mm) 2790
Overall Width (mm) 990
Overall Height (mm) 1765
Weight
Vehicle kerb Weight (Kg.) 383
Vehicle Gross Weight (Kg.) 763
Accessories (Optional)
Windshield, Stepney cover, Floor mat, Curtain, FM with speaker, Mobile holder & charger, Fog lamp, Rear view camera, Antitheft device and Roof Carrier
