| Motor |
BLDC Motor, 48V (1.0kW OR 1.2kW) |
| Battery |
Lead Acid (12V x 4 Nos.) 120Ah OR 130 Ah |
| Battery Charger |
48V, 15Amp, SMPS Type |
| Controller |
48 V, 50 Amps, 24 Tube MOSFET |
| Differential |
35 inch direct drive (Single speed OR Twin speed) |
| Electricals |
|
| DC-DC Converter |
48V-12V, 15Amp |
| System Voltage |
DC, 12V |
| Speedometer |
Digital OR Analog |
| Horn |
12V, I Cat Approved |
| Head light |
DC 12V, HS1 Bulb, High BeamLow Beam |
| Lights (Front Indicator / Position lamp, Licence lamp, Indicator / Reverse lamp, Parking / Brake lamp) |
DC 12V, LED Type |
| Dimensions |
|
| Overall Length (mm) |
2790 |
| Overall Width (mm) |
990 |
| Overall Height (mm) |
1765 |
| Accessories (Optional) |
|
| Windshield, Floor mat, Curtain, FM with speaker, Mobile holder & charger, Antitheft device and Curtain for driver |
